KENWORTH 4 ROW BOLT TOGETHER RADIATOR(W/SURGE TANK): 2006 & NEWER T600
New 4-row copper brass radiator for 2006 and newer Kenworth T600. Please confirm the lower tank connection and OE number match your application to ensure proper fit and performance.
This radiator features a 4-row serpentine-style core that measures 40" x 28-1/2" x 2-1/16".
Related core-only replacement options:
For the standard heavy-duty core see part 5633018-4HE.
For a dimpled tube heavy-duty core see pat 5633018-LHD.
This radiator includes surge tank 557024. See related items below for the mounting kit and bushing kit for this application.
Please note the upper connection on this radiator is curved and measures 2-1/2" and the lower connection measures 2-1/2".
For a similar radiator with a curved upper connection that measures 2-1/2" and a lower connection that measures 3" see part 556213-4.
For a similar radiator with a straight upper connection that measures 2-1/2" and a lower connection that measures 3" see part 559209.
| Part Number | SKU | 559158 |
|---|---|
| Make | KENWORTH |
| Material | COPPER / BRASS / STEEL TANK |
| Type | DOWNFLOW |
| Framework | YES |
| Core Height | 40" |
| Core Width | 28-1/2" |
| Inlet | 2-1/2" UPPER LEFT AT 8" (CURVED) |
| Outlet | 2-1/2" LOWER RIGHT AT 8-1/2" |
| Rows | 4 |
| Oil Cooler | NO |
| Depth | 2-1/16" |
| Warranty | 2-YEAR UNLIMITED MILEAGE WARRANTY COVERING MANUFACTURER DEFECTS. |
| OEM | Aftermarket Numbers | 559158 6500-20 650020 239158 SCSI239158 TR9158 KEN12 SRM6213-6082 RADKE112 X560120 X560109 1720178 E4313 X5601-20 40313 X560120 T64A 26020 |
| Notes | SHIPS TRUCK FREIGHT ONLY. |
